UltraStock® Select

Refined fiber composition and tight, uniform density for routing, cutting and shaping
Manufactured with 100% NAF resin
Surface is suitable for paints, stains, veneers or laminates

Product Details

UltraStock® products are manufactured with 100% NAF resins to provide optimized panel solutions for a wide selection of performance characteristics. You’ll love working with the smooth, consistent face – and you’ll see right away why it’s designed for demanding contouring and machining applications. UltraStock® Select is ideal for routing, cutting and shaping – along with RTF Cabinet Door and other critical machining applications.

Product Specifications

DIMENSIONS

Thicknesses	1/4” – 1-1/8”
Widths	To 5’
Lengths	To 16’

PHYSICAL PROPERTIES

Min Panel Averages ¹	1/4” to <1/2”	1/2” to 1-1/8”
MOR-Modulus of Rupture (psi)	4050	4050
MOE-Modulus of Elasticity (kpsi)	405	405
IB-Internal Bond (psi)	120	120
Face Screw Holding Capacity (lbs)	270	270
Edge Screw Holding Capacity (lbs) (2)	NA	250
24-Hour Thickness Swell	<0.0325”	<5.5%

¹ One-panel minimum average per ANSI 208.2 2. Not applicable for thinner than 5/8”

TOLERANCES

Recycled Content (MR credit 4)	Awards 1 or 2 points for using products with recycled content that constitute at least 10% or 20%, based on cost, of the total value of project materials.
Regional Materials (MR credit 5)	Awards 1 or 2 points for using materials on a project that are extracted and manufactured within 500 miles that constitute at least 10% or 20%, based on cost, of the total value of project materials.
Environmental Quality (EQ credit 4.4)	Requires composite wood products used on project to demonstrate documented compliance with California Air Resources Board ATCM formaldehyde requirements for ultra-low-emitting formaldehyde (ULEF) resins or no-added-formaldehyde (NAF) resins.
Low-VOC Emitting Materials (G2.9)	Specifies architects to select low-VOC emitting materials
Pre-consumer Recycled Content (604.1(2))	Use recycled content products in major areas such as walls, floor, insulation and roofing.

CERTIFICATIONS

ECC CERTIFICATION	UltraStock products produced in the Georgia-Pacific facility in Mt. Jewett, Pennsylvania, have been awarded the Composite Panel Association (CPA) Eco-Certified Composite (ECC) grademark which verifies compliance with the CPA 4-19 ECC Sustainability Standard, the California Air Resources Board (CARB) Airborne Toxic Control Measure (ATCM) 93120 and the EPA TSCA Title VI rule.
FSC® CERTIFICATION	UltraStock that is certified to conform to the requirements of Forest Stewardship Council® standards for FSC Mix Chain of Custody and Controlled Wood manufacturing is available by special order.
MR10 Designation	Based on ANSI A208.2 section 3.6, to receive the MR10 designation product samples must demonstrate the 24-hour thickness swell test value of 5.5% or less.
EPA TSCA, TITLE VI	All UltraStock is CARB and EPA TSCA Title VI compliant. This Product contains no Added Formaldehyde.
