Ply-Bead® Panels

Distinctive beaded look of tongue-and-groove planking
Resistant to dents, gouges, scuffs and scratches
For weather-protected ceiling, soffit, and wall applications.

Download

Product Details

Ply-Bead® Plywood Panels from Georgia-Pacific provide the rich, traditional look of expensive beadboard planking at a fraction of the cost and labor. Panels are resistant to dents, gouges, scuffs and scratches. This durability makes our Ply-Bead panels ideal for use in ceilings, walls and wainscoting. See them shine in high-traffic areas like bonus rooms, finished basements, playrooms, exercise rooms, bathrooms and laundry rooms. They’re also great for weather-protected areas like garages, porch ceilings and soffits.

Product Specifications

AVAILABLE SIZES (SIZED FOR 4’X8’)

Length (minimum)	7’-11 7/8” (2.435 m)
Width (minimum)	3’-11 7/8” (1.216 m)
Groove Spacing	1.6” on center spacing

BUILDING CODE PERFORMANCE CATEGORIES, PANEL THICKNESS

11/32 CAT

0.313” (7.95 mm)

SPECIFICATIONS

Length/Width Tolerance	+0, -1/16” (+0, -1.6 mm), based on 4’ or 8’ value
Straightness Tolerance	± 1/16” (± 1.6 mm)
Squareness Tolerance	± 1/8” (± 3.2 mm)
Primary Species	Southern Yellow Pine
Classification	Exposure 1 : Plywood suitable for uses not permanently exposed to the weather. Panels classified as Exposure 1 are intended to resist the effects of moisture on structural performance as may occur due to construction delays, or other conditions of similar severity.
Code Fire Classification	Class III or C
Flame Spread Rating	76-200, smoke developed index <450
Building Code Compliance	PS 1-22
