Product Details
DensArmor Plus® Interior Panels, which feature fiberglass mats instead of the paper facings used on the surface of traditional gypsum board products, resist mold growth. They’re ideal for areas prone to high humidity such as basements and residential bathrooms, and are ideal for commercial installations. They are designed for direct attachment with screws or nails to wood and metal framing or existing surfaces.
MOLD RESISTANCE
DensArmor Plus® Interior Panels, which feature fiberglass mats instead of the paper facings used on the surface of traditional gypsum board products, resist mold growth. When tested, as manufactured, in accordance with ASTM D3273, DensArmor Plus® Interior Panels have scored a 10, the highest level of performance for mold resistance under the ASTM D3273 test method, a testing method set by ASTM International, which develops testing guidelines and procedures for building materials, products, systems and services. The score of 10, in the ASTM D3273 test, indicates no mold growth in a 4-week controlled laboratory test. In addition, the mold resistance of DensArmor Plus® Interior Panels have been validated by UL Environment and listed in its Sustainable Product Guide utilizing microbial resistant testing based on ASTM Standard D6329.
The mold resistance of any building product when used in actual job site conditions may not produce the same results as were achieved in the controlled, laboratory setting. No material can be considered mold proof. When properly used with good design, handling and construction practices, DensArmor Plus® Interior Panels provide increased mold resistance compared to standard paper-faced gypsum products. For additional information, go to www.buildgp.com/safetyinfo.
LOW VOC EMISSIONS
DensArmor Plus® Interior Panels were the first fiberglass mat interior gypsum panels to be certified by UL Environment, an independent safety science company, as GREENGUARD and GREENGUARD Gold for low VOC emissions and are included in UL Environment’s Sustainable Product Guide.
Product Specifications
PHYSICAL PROPERTIES
| Thickness | nominal: 1/2″ (12.7 mm) ± 1/64″ (0.4 mm) |
| Width | standard: 4′ (1219 mm) ± 3/32″ (2.4 mm) |
| Length | standard: 8′ (2438 mm) to 12′ (3658 mm) ± 1/4″ (6.4 mm) |
| Weight | lbs/sq. ft. nominal (kg/m²): 2.0 (9.8) |
| R Value | °F•ft2•hr/BTU (m2•K/W): .56 (0.099) |
| Humidified Deflection | ≤2/8″ (6.4 mm) |
| Thickness | nominal: 5/8″ (15.9 mm) ± 1/64″ (0.4 mm) |
| Width | standard: 4′ (1219 mm) ± 3/32″ (2.4 mm) |
| Length | standard: 8′ (2438 mm) to 12′ (3658 mm) ± 1/4″ (6.4 mm) |
| Weight | lbs/sq. ft. nominal (kg/m²): 2.5 (12.2)1 |
| R Value | °F•ft2•hr/BTU (m2•K/W): 0.67 (0.118)2 |
| Humidified Deflection | ≤1/8″ (3 mm)3 |
Specific products may not be available in all markets. Contact your sales representative for product availability
1 Represents approximate weight for design and shipping purposes. Actual weight may vary depending on manufacturing location and other factors.
2 Tested in accordance with ASTM C518
3 Tested in accordance with ASTM C473
CERTIFICATIONS
Resources
FAQs
Yes; any interior wall, basement wall, laundry room or ceiling that is in an area prone to high humidity are sound applications.
No. DensArmor Plus® panels should not be used on exterior applications. See DensGlass® Sheathing.
Yes, DensArmor Plus® panels are suitable for soffit applications where it is not exposed directly to the elements. It can be finished using a setting-type joint compound prior to priming and painting.
